EnGenius EOC-3610S EXT Outdoor 600Mw Wireless Access Point/Client Bridge with External 5 dBi Omni Antenna 802.11b/g

Spausk čia vaizdo padidinimui	Kaina: 531.78Lt (439.49Lt be PVM) Kodas: EOC-3610s EXT Kiek.:	Svarbiausi momentai: EOC-3610S EXT Wireless High Power and High Gain Client Bridge/Access Point/ WDS (wireless distribution system) operates in the 2.4 GHz frequency spectrum supporting the 802.11b (2.4GHz, 11Mbps) and the newer, faster 802.11g (2.4GHz, 54Mbps) wireless standards. It's the best way to add wireless capability to your existing wired network, or to add bandwidth to your wireless installation. EOC-3610S EXT has high transmitted output power and high receivable sensitivity. High output power and high sensitivity can extend range and coverage to reduce the roaming between APs to get more stability wireless connection. EOC-3610S EXT can collocate with any high gain antenna want for users’ environment. To protect your wireless connectivity, NOC-3610 EXT can encrypt all wireless transmissions through 64/128-bit WEP data encryption and also supports WPA2/WPA/802.1x for powerful security authentication. The MAC addresses filter lets you select exactly which stations should have access to your network.
Pridėti į krepšelį Žiūrėti krepšelį Ištikrinti

Aprašymas

Technical Specifications

Data Rates
1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps

Standards
IEEE802.11b/g, IEEE802.3, IEEE802.3u, IEEE802.3af, IEEE802.1f, IEEE802.1x

Compatibility
IEEE 802.11g/ IEEE 802.11b

Power Requirements
Active Ethernet (Power over Ethernet) –48 VDC/0.375A
External Unit: Auto sensing 100/240 VAC; 50/60 Hz

Regulation Certifications
FCC Part 15 B & C,
CE: EN 300328, EN 301489
EN 60950

RF INFORMATION

Frequency Band
802.11b/g: U.S., Europe and Japan product covering 2.4 to 2.484 GHz, programmable for different country regulations

Media Access Protocol
Carrier Sense Multiple Access with Collision Avoidance (CSMA/CA)

Modulation Technology
Orthogonal Frequency Division Multiplexing (OFDM)
DBPSK @ 1Mbps
DQPSK @2Mbps
CCK @ 5.5 & 11Mbps
BPSK @ 6 and 9 Mbps
QPSK @ 12 and 18 Mbps
16-QAM @ 24 and 36 Mbps
64-QAM @ 48 and 54 Mbps

Operating Channels
11 for North America
14 for Japan
13 for Europe
Receive Sensitivity (Typical)
802.11g:
-90 dBm @ 6Mbps,
-74 dBm @ 54Mbp
802.11b:
-95 dBm @ 1Mbps
-90 dBm @ 11Mbps

Available transmit power
(Typical)
• 2.4~2.462G(IEEE802.11g)
27dBm @6 ~ 24Mbps
25dBm@36Mbps
24 dBm@48Mbps
23dBm@54Mbps
• 2.4~2.462G(IEEE802.11b)
28dBm. @1, 2, 5.5 and 11Mbps

RF Connector
SMA (Female Reverse) Type

NETWORKING

Topology
Ad-Hoc, Infrastructure

Operation Mode
Point-to-Point/ Point-to-Multipoint Bridge/ AP/ Client Bridge/ WDS

Interface
Wireless IEEE802.11b/g
One 10/100 RJ-45 port
One console RS-232 port

Security
- IEEE802.1x Authenticator / RADIUS Client (EAP-MD5/TLS/TTLS) Support in AP Mode
- WPA/WPA2 Supplicant support in Client Bridge Mode
- WPA /WPA2/ Pre Share KEY (PSK) with TKIP/AES
- MAC address filtering (AP only)
- Hide SSID in beacons
- VLAN Pass-through
- L2 Isolation(AP mode)

Configuration
Web-based configuration (HTTP)
Telnet Configuration

IP Auto-configuration
DHCP client/server

Management
SNMP V1, V2c, MIBI&II

Firmware Upgrade
Upgrade firmware via web-browser

PHYSICAL

Dimensions (HxWxD)
163.8(L)mm * 135.2(W)mm * 47.0(H)mm

Weight
1.2 Kg (2.6 lbs)

ENVIRONMENT

Temperature Range
Operating: -0°C to 60°
Storage: -20°Cto 80°

Humidity (non-condensing)
5%~95% Typical

Package Contents
- Outdoor Wireless Client Bridge unit
- 48V, 0.375A AC/DC adapter with wall-plug power code
- One 5dBi SMA dipole antenna.
- Inline Power Injector (PoE)
- 1.8m Grounding Cable
- User manual CD-disc
- Wall mounting kit
- Mast mounting kit
