Technical Specifications



Data Rates

1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps



Standards

IEEE802.11a/b/g, IEEE802.3, IEEE802.3u, IEEE802.3af, IEEE802.1f, IEEE802.1x



Compatibility

IEEE 802.11g/ IEEE 802.11b



Power Requirements

Active Ethernet (Power over Ethernet) –48 VDC/0.375A

External Unit: Auto sensing 100/240 VAC; 50/60 Hz



Regulation Certifications

FCC Part 15/UL, ETSI 300/328/CE



RF INFORMATION



Frequency Band

802.11a: 5.15~5.25GHz, 5.25~5.35GHz, 5.47~5.725GHz, 5.725~5.825GHz

802.11b/g: U.S., Europe and Japan product covering 2.4 to 2.484 GHz,

programmable for different country regulations



Media Access Protocol

Carrier Sense Multiple Access with Collision Avoidance (CSMA/CA)



Modulation Technology

Orthogonal Frequency Division Multiplexing (OFDM)

DBPSK @ 1Mbps

DQPSK @2Mbps

CCK @ 5.5 & 11Mbps

BPSK @ 6 and 9 Mbps

QPSK @ 12 and 18 Mbps

16-QAM @ 24 and 36 Mbps

64-QAM @ 48 and 54 Mbps



Operating Channels

802.11b/g:

11 for North America, 14 for Japan, 13 for Europe,

802.11a:

US/Canada:12 non-overlapping channel (5.15~5.35GHz, 5.725~5.825GHz)

Europe:19 non-overlapping channel (5.15~5.35GHz, 5.47~5.825GHz)

Japan: 4 non-overlapping channel (5.15~5.25GHz)

China: 5 non-overlapping channel (5.725~5.85GHz)



Receive Sensitivity (Typical)

802.11a:

-88dBm @ 6Mbps,

-70dBm @ 54Mbps

802.11g:

-90 dBm @ 6Mbps,

-74 dBm @ 54Mbp

802.11b:

-95 dBm @ 1Mbps

-90 dBm @ 11Mbps



Available transmit power (Typical)

• 5.15~5.24 GHz(IEEE802.11a)

17 dBm @6 ~ 24Mbps

17 dBm @36Mbps

16 dBm @48Mbps

15 dBm @54Mbps

• 5.26~5.35GHz(IEEE802.11a)

20dBm @6 ~ 24Mbps

18dBm @36Mbps

16 dBm @48Mbps

15 dBm @54Mbps

• 5.745~5.85GHz (IEEE802.11a)

18dBm @6 ~ 24Mbps

16dBm @36Mbps

14 dBm @48Mbps

13 dBm @54Mbps

• 2.412~2.472G(IEEE802.11g)

up to 26dBm @6 ~ 24Mbps

23dBm @36Mbps

22 dBm @48Mbps

21 dBm @54Mbps

• 2.412~2.472G(IEEE802.11b)

up to 26 dBm. @1, 2, 5.5 and

11Mbps



RF Connector

SMA (Fr) Type for 2.4/5GHz



NETWORKING



Topology

Ad-Hoc, Infrastructure
