| Electrical |
|---|
|
Frequency range |
4.9 - 6.1 GHz |
|
Gain,typ. |
26 dBi |
|
VSWR, max. |
4.9 - 5.875 @ 1.7 : 1 5.875 - 6.1 @ 2 : 1 |
|
3 dB Beam-Width, H-Plane, typ. |
7.5 ° |
|
3 dB Beam-Width, E-Plane, typ. |
7.5 ° |
|
Side Lobes, min. |
ETSI TS3, TS4, TS5 |
| Polarization |
Linear,Vertical or Horizontal |
| Cross Polarization, min. |
ETSI TS3, TS4, TS5 |
| Front to Back Ratio, min. |
ETSI TS3, TS4, TS5 |
| Input power, max |
50 Watt |
| Input Impedance |
50 Ohm |
| Lightning Protection |
DC Grounded |
| Mechanical |
|---|
| Dimensions (HxWxD) | 370 x 370 x 30 mm (14.6"x14.6"x1.2") |
| Weight | 3 kg |
| Connector | N-Type, Female |
| Back Plane | Aluminum; protected through chemical passivation |
| Radome | UV Protected, Plastic |
| Mount | MNT-22 |
| Environmemtal |
|---|
| Operating Temperature Range | -40° C to +65° C |
| Vibration | According to IEC 60721-3-4 |
| Wind Load | 200 km/h (survival) |
| Flammability | UL94 |
| Water Proofing | IP-67 |
| Humidity | ETS 300 019-1-4, EN 302 085 (annex. A.1.1) |
| Salt Fog | According to IEC 68-2-11 |
| Service Life | > 10 years |
Specification PDFTurite klausimų? Susisiekite...
|
