Pristatymas - 14 dienų| Electrical |
|---|
|
Frequency range |
4.9 - 5.875 GHz |
|
Gain, min. |
18 dBi @5.15-5.875 GHz, 16 dBi@4.9-5.15 GHz |
|
VSWR, max. |
1.5: 1@5.15-5.875, 1.8:1@4.9-5.15 |
|
3 dB Beam-Width, H-Plane, typ. |
21 ° |
|
3 dB Beam-Width, E-Plane, typ. |
19 ° |
|
Side Lobes, min. |
-12 dB |
| Polarization |
Linear, Vertical (Horizontal with MNT-2 Option) |
| Cross Polarization, min. |
-20 dB |
| Front to Back Ratio, min. |
-30 dB |
| Input power, max |
30 Watt |
| Input Impedance |
50 Ohm |
| Lightning Protection |
DC Grounded |
| Mechanical |
|---|
| Dimensions (HxWxD) | 150 x 150 x 26 mm (5.9"x 5.9"x 1") |
| Weight | 240 gr. |
| Connector | N-Type, Female/ SMA Female (See Ordering Options) |
| Back Plane | Aluminum; protected through chemical passivation |
| Radome | UV Protected, Plastic |
| Mount | MNT-2 |
| Environmemtal |
|---|
| Operating Temperature Range | -40° C to +65° C |
| Vibration | According to IEC 60721-3-4 |
| Wind Load | 200 km/h (survival) |
| Flammability | UL94 |
| Water Proofing | IP-65 |
| Humidity | ETS 300 019-1-4, EN 302 085 (annex. A.1.1) |
| Ice and Snow | 25 mm radial (survival) |
| Salt Fog | According to IEC 68-2-11 |
| Service Life | > 10 years |
| Standard Compliance |
|---|
| ETSI EN 302 085 V1.2.3 TS1, TS2 |
