Main Features
Output Power per Channel
180 W
Impedance at Output Level
6Ī©
Number of Channels 7
Signal / Noise Ratio
103 dB
Input Connections
- 6 x HDMI (1080p upscaling) (1 Front Input)
- 4 x Composite In
- 3 x Component In
- 2 x Coaxial In
- 3 x Optical In
- 1 x USB / iPod/iPhone
- 1 x Ethernet
- 1 x Bluetooth adapter port for AS-BT100 (included)
Output Connections
- 2 x HDMI
- 1 x Composite
- 1 x Component
- 1 x Optical
Tuner Pre-set Stations
63
Internet Radio
Yes
THX Certified (+)
Yes
THX, the inspiration of George Lucas, was originally created for optimum performance in movie theatres.
THX Certified products guarantee superior performance and ensure accurate reproduction of the theatre experience in your home.
To be THX Certified requires adherence to rigorous guidelines for sound purity, power output and processing capabilities.
AIR Studio Sound Tuning (+)
Yes
AIR Studios Tuning is a benchmark of high fidelity sound. What it means
is that engineers from AIR Studios have put the system through rigorous
tuning, determined to deliver audio output that is as pure and precise
to the original as possible.
AIR Studios was founded by Sir George Martin, legendary Beatles producer
and Academy Award-nominated composer. Sir Martin is also one of
music's most versatile and imaginative talents.
Established in 1969, Londonās AIR Studios is now a state-of-the-art
recording complex with matchless facilities for film scoring, rock, pop,
classical and orchestral work, postproduction and live events.
Many of the world's most popular and renowned musical talents have
worked in this unique and inspirational recording environment.
HD Digital Film Direct 24 (+)
Yes
Put
simply, HD Digital Film Direct means āMaster Qualityā: what you see and
hear on your flat-screen is exactly as the film-makers intended.
Absolutely true to the original.
Weāve applied this standard as a label (see the logo on the right) to
those of our products that accurately handle 24fps (frames per second)
movie content; this will help you make the right product choice for the
true HD movie experience.
Films are typically shot, developed and encoded for cinema reproduction at 24fps.
Regular PAL broadcasting and DVD have always played these images back at 25 fps (50Hz).
This has the effect of speeding up images and raising the pitch of sounds and voices.
But, the new high definition discs, like Blu-ray Disc, offer you
access to a digitised ātrue to the originalā copy of the theatrical
movie content.
We offer a product range that is perfectly matched for bringing the
real cinema experience into your home: amplifiers, Blu-ray Disc players,
home cinema systems and flat-screen TVs with our trademark screening of
24fps source input at 72Hz (3 images displayed per original frame).
MCACC (+)
Yes (Advanced, 9-band)
MCACC stands for Multi-Channel Acoustic Calibration System.
It's an automatic sound field adjustment system that enables you to
precision-tune your system to your living room, just like a sound
professional, but with minimum effort.
A microphone monitors the sound environment and an equaliser (either 5
or 9-band, depending on which model of amplifier you have) optimally
adjusts the sound parameters.
The result sounds like a professional recording engineer has fine-tuned your amplifier or home cinema system.
MCACC was created as a joint effort between ourselves and professional
sound engineers at AIR Studios; it's unique to Pioneer, so you won't
find it on any other products.
See how MCACC works
HD Audio Formats
Dolby TrueHD, DTS-HD Master
Audio, DTS-HD High Resolution
Audio Return Channel Yes
Control with HDMI (+)
Yes
Put simply, KURO LINK means that you are able to control basic functions
of compatible Pioneer Audio/Visual devices* (such as your Blu-ray
player, amplifier or DVD recorder), with your KURO flat-screen TV remote
control.
One remote for your full entertainment system.
KURO LINK is made possible via the single HDMI cable connection between
your flat-screen TV and your other entertainment devices.
* Other brands of TV and home entertainment components also work with the KURO LINK function (
hereās a list)
Deep Colour (+)
Yes
Deep Colour ensures that all colour transitions and gradients are reproduced with the highest level of precision.
It enables increased contrast ratio, eliminates on-screen colour banding
(for smooth tonal transitions and subtle gradations between colours)
and can represent many times more shades of gray between black and
white.
So what you see is as natural and lifelike as possible.
x.v.Colour (+)
Yes
x.v.Colour (also known as xvYCC or Extended-gamut YCC) is a colour space
that supports 1.8 times as many colours as the legacy colour space.
The result is that ā on a compatible screen - you see greens, reds and blues far deeper than previously possible.
HDMI Repeater (+)
Yes
The HDMI Repeater feature makes a single HDMI cable sufficient to transfer both HD video and audio digitally to the receiver.
3D Ready
Yes
On-Screen Display (GUI) Easy-to-use GUI, available in English,
French, Italian, German, Spanish,
Dutch and Russian
Remote Control
Glow-key, preset remote control
(learning)
Power Consumption (in use / standby) 330 W / 0.30 W
Weight
18,5 kg
Dimensions (W x H x D)
420 x 200 x 460 mm
